type Header struct {
ParentHash common.Hash `json:"parentHash" gencodec:"required"`
UncleHash common.Hash `json:"sha3Uncles" gencodec:"required"`
Coinbase common.Address `json:"miner" gencodec:"required"`
Root common.Hash `json:"stateRoot" gencodec:"required"`
TxHash common.Hash `json:"transactionsRoot" gencodec:"required"`
ReceiptHash common.Hash `json:"receiptsRoot" gencodec:"required"`
Bloom Bloom `json:"logsBloom" gencodec:"required"`
Difficulty *big.Int `json:"difficulty" gencodec:"required"`
Number *big.Int `json:"number" gencodec:"required"`
GasLimit uint64 `json:"gasLimit" gencodec:"required"`
GasUsed uint64 `json:"gasUsed" gencodec:"required"`
Time *big.Int `json:"timestamp" gencodec:"required"`
Extra []byte `json:"extraData" gencodec:"required"`
MixDigest common.Hash `json:"mixHash" gencodec:"required"`
Nonce BlockNonce `json:"nonce" gencodec:"required"`
}
|
状态树、交易树和收据树
Root状态树，数据结构为MPT(Merkle Patricia Tree)，针对更新的状态创建新的分支，包含之前的状态树。每一个区块TxHash和ReceiptHash分别是一棵MPT树。
bloom filter
bloom filter用于查找某个元素是否在集合里，是一个基于概率的数据结构：过滤掉的元素一定不在集合里，但通过滤器的元素未必在集合里。 Bloom filter基于一个比特向量( Bit Vector) 定位一个元素，
举例：一共有n元素经过bloom filter，bloom filter中一共有m各比特，需要k个hash函数分别计算元素的k个向量，则k的选取为k: (m/n)ln(2)
// the wordSize of a bit set
const wordSize = uint(64)
// log2WordSize is lg(wordSize)
const log2WordSize = uint(6)
»
GHOST协议
叔块：祖先的兄弟(不包含父亲的兄弟)
以太坊鼓励分叉合并的方案。叔块奖励最多到前7代，奖励比例依次为$$ \frac{7}{8} 、\frac{6}{8} 、\frac{5}{8} 、\frac{4}{8} 、\frac{3}{8} 、 \frac{2}{8} $$ ， 每个区块最多包含2个叔块，每包含一个叔块的区块也会得到$$\frac{1}{32} blcokReward$$ 的奖励。验证区块只验证其难度，不验证里面的交易。
智能合约
交易只能由外部账户发起
合约之间调用
-
直接调用
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
|
contract A {
event LogCallFoo(string str);
function foo(string str) return (uint){
emit LogCallFoo(str);
return 123;
}
}
contract B {
uint ua
function callAFooDirectly(address addr){
A a = A(addr);
ua = a.foo("call foo directly"); // 此执行a.foo()过程中抛出错误，则callAFooDirectly也抛出错误，本次调用全部回滚。
}
}
|
-
使用address 类型的call()函数
1
2
3
4
5
6
7
8
|
contract C {
function callAFooByCall(address addr) public returns (bool) {
bytes4 funcsig = bytes4(keccak256("foo(string)"));
if(addr.call(funcsig, "call foo by func call")) //无法获取函数返回值
return true;
return false;
}
}
|
fallback()函数
1
2
3
|
function() public [payable] {
...
}
|
- 匿名函数，没有参数也没有返回值
- 在两种情况下被调用
- 直接向一个合约地址转账而不加任何data
- 被调用的函数不存在
- 如果转账金额不是0，同样需要声明payable, 否则会抛出异常
智能合约创建和允许
创建: 代码编译成bytecode放入data中，发起交易to为0x0
运行：在EVM(Ethereum Virtual Machine)上
汽油费(gas fee)
增加攻击成本
Block的gasLimit作用：对区块交易所消耗的资源进行限制，类似比特币对区块大小的限制。矿工可以在之前的区块的gaslimit 对当前区块的gaslimit上下条1/1024比例。
错误处理
- 不存在try-catch
- 出现异常回滚
- 可以抛错误的语句：
- assert(bool condition): 如果条件不满足就抛出—-用于内部错误
- require(bool condition)
- revert(): 终止运行并会滚状态变动。
嵌套调用
具体情况具体考虑
挖矿和执行职能合约的先后顺序？
先执行执行智能合约，更新三棵树(Root, ReceiptHash, TxHash)。每个全节点还要对智能合约执行一遍以对发布的区块验证。验证需要执行交易一遍并更新本地数据库的三棵树以验证块头信息。发布的区块了没有三棵树全部具体内容，只是块头里有根其对应的根hash值。
智能合约支持多线程吗
不支持。多核访问内存顺序不同，执行结果不确定。而且所有不确定的执行都不会支持，如java的生成随机数。
智能合约可以获取的区块信息
block.blockhash(uint blockNumber) returns (bytes32) 给定区块的hash，仅对最近的256个区块有效，不包含当前区块block.coinbaseblock.difficultyblock.gaslimitblock.numberblock.timestamp
智能合约可以获得的调用信息
msg.data(bytes) 完整的calldatamsg.gas(uint) ，剩余的gas决定了还可以做什么动作msg.sender(address)msg.sig(bytes4) calldata的前4个字节，也就是函数标识符msg.value(uint)nowtx.gaspricetx.origin 交易的发起者，A->C->B, B中 A为tx.origin
地址类型
balancetransfer(uint256 amount) 向地址类型发送amount的wei，失败时抛出异常，发送2300 gas的矿工费，不可调节send(uint256 amount) returns (bool) 向地址类型发送数量为amount 的wei,失败时返回false, 发送2300 gas的矿工费，不可调节。call(...) returns (bool) 发出底层call,失败返回false,发送所有gas，不可调节。callcode(...) returns (bool) 发出底层callcode, 失败返回false,发送所有可用的gas, 不可调节。deletegatecall(...) returns (bool) 。发出底层callcode, 失败返回false,发送所有可用的gas, 不可调节。
漏洞
1
2
3
4
5
6
7
8
9
10
11
12
13
14
|
美链
function batchTransfer(address[] _receivers, uint256 _value){
uint cnt = _receivers.length;
uint256 amount = uint256(cnt) * _value; //溢出可能
require(cnt > 0 && cnt<=20);
require(_value>0 && balances[msg.sender]>=amount);
balances[msg.sender] = balances[msg.sender].sub(amount);
for(uint i=0; i<cnt; i++){
balances[_recievers[i]] = balances[_recievers[i]].add(_value);
Transfer(msg.sender, _receivers[i], _value);
}
}
|
美链攻击细节
1
2
3
4
5
6
7
8
9
10
|
function: batachTransfer(address[] _recievers, uint256 _value)
MethodID:0x83f12ec
[0]: 00000000000000000000000000000040 //第一个参数出现在4*16个字节位置
[1]: 80000000000000000000000000000000 //_value值
[2]: 00000000000000000000000000000002 //数组长度
[3]: 00000000000000003333333333333333 // 接收的地址
[4]: 00000000000000004444444444444444 //接收的地址
计算溢出的amout恰好为0，
使用SafeMath库
|
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
20
21
22
23
24
25
26
27
28
29
30
31
32
33
34
35
36
37
38
39
40
41
42
43
44
45
46
47
48
49
50
51
52
53
|
下面为两个有问题合约，它们没有考虑被恶意合约调用可能
第一版本：
function bid() public payable {
require(now <= auctionEnd);
require(bids[msg.sender]+msg.value > bids[highestBidder]);
if(!(bids[msg.sender] == uint(0))){
bidders.push(msg.sender);
}
highestBidder = msg.sender;
bids[msg.sender] += msg.value;
emit HighestBidIncreased(msg.sender, bids[msg.sender]);
}
function acutionEnd() public {
require(now > autionEnd);
require(!ended);
beneficiary.transfer(bids[highestBidder]);
for(uint i = 0; i< bidders.length;i++){
address bidder = bidders[i];
if(bidder == highestBidder) continue;
bidder.transfer(bids[bidder]);
}
}
第二版本：
function withdraw() public returns (bool) {
require(now > autionEnd);
require(msg.sender != highestBidder);
require(bids[msg.sender] > 0);
uint amount = bids[msg.sender];
if(msg.sender.call.value(amount)()){ //可重复攻击
bids[msg.sender] = 0;
return true;
}
return false;
}
function pay2Beneficiary(address winner, uint amount){
require(now > auctionEnd);
require(bids[highestBidder] > 0);
uint amount = bids[highestBidder];
bids[highestBidder] = 0;
emit Pay2Beneficiary(highestBidder, bids[highestBidder]);
if(!beneficiary.call.value(amount)()){
bids[highestBidder] = amount;
return false;
}
return true;
}
|
最新完整安全合约参考
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
20
21
22
23
24
25
26
27
28
29
30
31
32
33
34
35
36
37
38
39
40
41
42
43
44
45
46
47
48
49
50
51
52
53
54
55
56
57
58
59
60
61
62
63
64
65
66
67
68
69
70
71
72
73
74
75
76
77
78
79
80
81
82
83
84
85
86
87
88
89
90
91
92
93
94
95
96
97
98
99
100
101
102
103
104
105
106
107
108
109
110
111
112
113
114
115
116
117
118
119
120
121
122
123
124
125
126
127
|
pragma solidity >=0.4.22 <0.7.0;
contract SimpleAuction {
// Parameters of the auction. Times are either
// absolute unix timestamps (seconds since 1970-01-01)
// or time periods in seconds.
address payable public beneficiary;
uint public auctionEndTime;
// Current state of the auction.
address public highestBidder;
uint public highestBid;
// Allowed withdrawals of previous bids
mapping(address => uint) pendingReturns;
// Set to true at the end, disallows any change.
// By default initialized to `false`.
bool ended;
// Events that will be emitted on changes.
event HighestBidIncreased(address bidder, uint amount);
event AuctionEnded(address winner, uint amount);
// The following is a so-called natspec comment,
// recognizable by the three slashes.
// It will be shown when the user is asked to
// confirm a transaction.
/// Create a simple auction with `_biddingTime`
/// seconds bidding time on behalf of the
/// beneficiary address `_beneficiary`.
constructor(
uint _biddingTime,
address payable _beneficiary
) public {
beneficiary = _beneficiary;
auctionEndTime = now + _biddingTime;
}
/// Bid on the auction with the value sent
/// together with this transaction.
/// The value will only be refunded if the
/// auction is not won.
function bid() public payable {
// No arguments are necessary, all
// information is already part of
// the transaction. The keyword payable
// is required for the function to
// be able to receive Ether.
// Revert the call if the bidding
// period is over.
require(
now <= auctionEndTime,
"Auction already ended."
);
// If the bid is not higher, send the
// money back (the failing require
// will revert all changes in this
// function execution including
// it having received the money).
require(
msg.value > highestBid,
"There already is a higher bid."
);
if (highestBid != 0) {
// Sending back the money by simply using
// highestBidder.send(highestBid) is a security risk
// because it could execute an untrusted contract.
// It is always safer to let the recipients
// withdraw their money themselves.
pendingReturns[highestBidder] += highestBid;
}
highestBidder = msg.sender;
highestBid = msg.value;
emit HighestBidIncreased(msg.sender, msg.value);
}
/// Withdraw a bid that was overbid.
function withdraw() public returns (bool) {
uint amount = pendingReturns[msg.sender];
if (amount > 0) {
// It is important to set this to zero because the recipient
// can call this function again as part of the receiving call
// before `send` returns.
pendingReturns[msg.sender] = 0;
if (!msg.sender.send(amount)) {
// No need to call throw here, just reset the amount owing
pendingReturns[msg.sender] = amount;
return false;
}
}
return true;
}
/// End the auction and send the highest bid
/// to the beneficiary.
function auctionEnd() public {
// It is a good guideline to structure functions that interact
// with other contracts (i.e. they call functions or send Ether)
// into three phases:
// 1. checking conditions
// 2. performing actions (potentially changing conditions)
// 3. interacting with other contracts
// If these phases are mixed up, the other contract could call
// back into the current contract and modify the state or cause
// effects (ether payout) to be performed multiple times.
// If functions called internally include interaction with external
// contracts, they also have to be considered interaction with
// external contracts.
// 1. Conditions
require(now >= auctionEndTime, "Auction not yet ended.");
require(!ended, "auctionEnd has already been called.");
// 2. Effects
ended = true;
emit AuctionEnded(highestBidder, highestBid);
// 3. Interaction
beneficiary.transfer(highestBid);
}
}
|
参考
https://llimllib.github.io/bloomfilter-tutorial/
